62 Series | SV Standard Female Coupling With Safety Sleeve (Steel)

Categories	Poppet (Interchange) Couplers
Interchange	FASTER SV SERIES
Update Time	Sep 24,2025

Detail Information

62 Series

Standard Female Coupling With Safety Sleeve (Steel)

Poppet Valve

This EH series is interchangeable with FASTER SV SERIES. Steel Product. Standard female couplings very similar to 66 series but equipped with an additional safety sleeve to prevent accidental disconnections. Poppet valve.

Female

Other Threads/Fitting Ends Are Available Upon Request
Art. No.	Body Size (inch)	Ls(mm)	D(mm)	Hs(mm)	T
HFSFC6214- G1/4''	1/4''	50	27	S24	BSPP 1/4" FEMALE
HFSFC6214- G1/2''	1/2''	66	38	S27	BSPP 1/2" FEMALE

Accessories

Technical Specifications

Dash Size	Body Size (Inch)	Max. Work PressureFemale (bar)	Min. Burst Pressure Female (bar)	Min. Burst Pressure Coupled (bar)	Spillage (ml)
04	1/4''	350	1400	1400	0.8
08	1/2''	300	1200	1300	1.8

Material:	Steel
Seals:	NBR, Seals can be customized to meet your special work condition/media
Working Temperatures:	-25 °C to 125 °C, Customizable
Surface Treatment:	MATE 500 (CrIII)
Specifications:	Series Interchange:	FASTER SV SERIES
	Valve Type:	Poppet
	Connection:	Push to Connect
	Disconnection:	Pull to Disconnect
	Connection Under Pressure:	Not Allowed
