Hydraulic Quick Release Couplings & Valves

This EH series is interchangeable with the RE577560 John Deere SCV Breakaway Quick Coupler. Steel Product. This durable coupler is engineered for long-term performance. Its fully serviceable design can be easily rebuilt, extending its service life and reducing downtime. To ensure exceptional corrosion resistance, it undergoes and passes a rigorous 200-hour salt spray test—a standard that translates to a projected 10-20 years of reliable operation in typical farm environments. It is also known as an SCV Coupler or ½ inch Coupler.

This EH series is interchangeable with the Faster 4BD4FH Spare Part Kit and Faster 4BD4FH Accessories. Steel Product. This pioneering cast iron block was the first of its kind to enable the rapid connection and disconnection of attachments for skid steer loaders and similar construction machinery. It utilizes cartridges that incorporate the full benefits of flat face coupler series technology, including a decompression feature for safe coupling even with residual pressure on both sides of the circuit. The block accepts both 1/2" and 3/4" cartridges, with the larger size providing a higher flow capacity while maintaining the same compact footprint.

This EH series is interchangeable with PISTER BKH SERIES, MHA BKH SERIES, HYDAC KHB SERIES, HYDAC KHM SERIES, CIOCCA CRHI2 SERIES, and GEMELS GE2 SERIES. Steel Product. Two-way high-pressure ball valve (STEEL), used in various industries including construction, agricultural machinery, water engineering, mining engineering, and paint industries.

This EH series is interchangeable with Parker 20 series, Parker 30 series, Hansen 1000 series, Hansen 3000 series, Rectus 23KA series, Rectus 24 series, Rectus 1400 series, Rectus 1423 series, CEJN 310 series, TEMA 1400 series, FOSTER 3/4/5/6 SERIES, GROMELLE 600 series, JWL 521 series, JWL 531 series, and Eaton 43 series pneumatic quick couplers.
Brass / Steel Product. This sleeve-type coupler accepts industrial interchange. It is widely used to connect air lines and low-pressure fluids. Its compact and economical design uses a ball locking mechanism consisting of captive steel balls that engage the locking groove on the mating nipple. The sliding spring-loaded sleeve on the coupler must be manually retracted to connect or disconnect the nipple. Common applications include compressed air, water, grease, paint, limited vacuum, and limited gases.

This EH series is interchangeable with STUCCHI DP PLATE SERIES. Steel Product. The multicoupling series offers an efficient solution for simultaneous hydraulic line connections, featuring multiple configurable sets of 3/8" or 1/2" plugs and couplers operated via a steel handle for quick, secure engagement. Designed for demanding applications, all couplers are zinc-nickel plated for corrosion resistance and support connect-under-pressure functionality, ensuring reliable performance in high-pressure systems. The modular design allows individual coupler replacement after reaching their recommended service life.

This EH series is interchangeable with PARKER H SERIES, PARKER IH SERIES, SNAP-TITE H SERIES, SNAP-TITE IH SERIES, DIXON V SERIES, FASTER TNV SERIES, FASTER TNL SERIES, DNP PNV1 SERIES, DNP PNO1 SERIES and STUCCHI SH SERIES. Steel Product. 105 series couplings are commonly used in US market as an alternative to standard series. Their valves have been designed to help flow and to allow connection with 106 parts (free flow) same series. Carbon Steel.

This EH series is interchangeable with PARKER 6100 SERIES, DIXON W SERIES, EATON AEROQUIP 5100 SERIES, FASTER FB SERIES, VOSWINKEL HM SERIES, SNAP-TITE 78 SERIES, SAFEWAY S51 SERIES, and HANSEN 96 WING NUT SERIES. Brass Product. Brass flat-face screw couplings specifically designed for vehicle and road machinery hydraulic systems. Features an ergonomic wing sleeve for tool-free operation, enabling easy manual connection/disconnection. Compliant with US interchange standards for seamless compatibility.

This EH series is interchangeable with PARKER 4000 SERIES, DIXON AG SERIES, EATON AEROQUIP FD42 SERIES, FASTER NS SERIES, DNP PDS1 SERIES, STUCCHI IR SERIES, SAFEWAY S20 SERIES, and SNAP-TITE 60 SERIES. Steel Product. ISO-5675 compliant. General-purpose ball valve couplings with quick-disconnect functionality. ISO-7241-A compliant (1/2'' Body Size Only). The rest body sizes are interchangeable with the PARKER 4000 series and Faster NS series. Note that the FASTER NS SERIES 3/4'' size is different from the PARKER 4000 Series 3/4'' size.

This EH series is interchangeable with STUCCHI VEP-P SERIES, PARKER FET SERIES, FASTER FHV SERIES, DNP PST4 SERIES, VOSWINKEL FT SERIES, DIXON VEP SERIES, and HOLMBURY HFT SERIES. Steel Product. Engineered for demanding hydraulic systems, the 297 Series provides reliable performance in applications subject to extreme pressure impulses and residual line pressures. The innovative thread-to-connect design significantly reduces wear and prevents brinelling, while the internal valve technology enables safe connection and disconnection even under high residual pressure conditions.

This EH series is interchangeable with the FASTER 6DNPV SERIES. Steel Product. Compliant with ISO 7241-1A, this series can be screwed directly into valve ports or rigid piping. It features a breakaway safety function: under excessive force, such as unintentional tractor pull, the coupling halves disconnect cleanly to prevent hose rupture and environmental spills. The male half can get manually disconnected under residual pressure up to 250 bar.

This EH series is interchangeable with MHA RV SERIES, PARKER 339 SERIES, and GROMELLE 654-Z SERIES. Stainless Steel Product. One-way stainless steel 316 check valve for in-line use. Suitable for any type of hydraulic applications. This series check valve allows flow in one direction and blocks it in the opposite direction. The flow is only allowed once a pre-set cracking pressure is reached. Customized cracking pressure is available. This series is widely used in corrosive environments: marine, oil and gas, chemical, pharmaceutical, and nuclear.

This EH series is interchangeable with PARKER H SERIES, PARKER IH SERIES, SNAP-TITE H SERIES, SNAP-TITE IH SERIES, DIXON V SERIES, FASTER TNV SERIES, FASTER TNL SERIES, DNP PNVX SERIES, DNP PNOX SERIES and STUCCHI SH SERIES. Stainless Steel Product. 103 series couplings are commonly used in US market as an alternative to standard series. Their valves have been designed to help flow and to allow connection with 104 parts (free flow) same series. AISI SS316 Material.

This EH series is interchangeable with PARKER 60 SERIES, DIXON H SERIES, EATON AEROQUIP FD45 SERIES, FASTER HNV STAINLESS STEEL SERIES, DNP PBVX SERIES, STUCCHI IRBX SERIES, HANSEN HK SERIES, SAFEWAY SS10 SERIES, VOSWINKEL IB-VA SERIES, and GROMELLE 635-Z SERIES. Stainless Steel Product. Standard couplings for industrial applications with stainless steel components (AISI 316). ISO 7241 part B interchange.

This EH series is interchangeable with STUCCHI VR SERIES, FASTER FLV SERIES, VOSWINKEL RH SERIES, VOSWINKEL RK SERIES, and DNP PRH3 SERIES. Steel Product. The 64 Series German Screw Coupler features a low-leakage valve for sealing and threaded connections, enabling secure mating even under residual pressure. Its robust construction makes it ideal for demanding applications, including mobile construction and industrial hydraulics.

This EH series is interchangeable with STUCCHI FIRG SERIES, DNP PLT1 SERIES, PARKER FF SERIES, EATON AEROQUIP FD 89 SERIES, DIXON HT SERIES, HANSEN QA29000 SERIES, and SAFEWAY FFE49 SERIES. Steel Product. The 95 Series, renowned as the original ISO 16028-compliant coupling solution, continues to deliver reliable performance, exceptional durability, and competitive value. Its innovative integrated sealing system significantly minimizes premature wear by effectively compensating for three critical stress factors: relative movement between coupling components, sudden pressure impulses, and the constant strain exerted by hose weight during horizontal operation.

This EH series is interchangeable with FASTER 3CFPV SERIES, PARKER RSD SERIES, DNP PPK3 SERIES, STAUFF UX SERIES, and VOSWINKEL UX SERIES. Steel Product. Designed for direct installation into valve ports or rigid piping systems, this coupling series meets stringent ISO 7241-1 Series A standards while incorporating critical safety features. The innovative breakaway function provides essential protection against equipment damage by automatically disconnecting the male coupling component when subjected to accidental tractor pull forces, effectively preventing hose rupture. This safety mechanism ensures operational reliability in demanding agricultural and industrial applications where unexpected tension may occur. Max Flow rate is 200 L/min.

This EH series is interchangeable with the FASTER NL SERIES. Steel Product. 61 couplings feature an open-passage design with no internal valves, ensuring higher flow efficiency and reduced pressure loss.

This EH series is interchangeable with MHA NDRV SERIES, HYDAC DRV SERIES, PARKER F SERIES, and GEMELS RF SERIES. Steel Product. One-way valve for flow control use. Suitable for any type of hydraulic system using liquid that is not highly viscous. The standard type is in zinc-plated carbon steel. It is mainly used in non-corrosive mineral-based oils and liquids.

This EH series is interchangeable with STUCCHI FL SERIES, CEJN X66 SERIES, PARKER FS SERIES, VOSWINKEL FH-VA SERIES, GROMELLE 629-Z SERIES, FASTER 2FFI Stainless Steel SERIES, DNP PLTX SERIES, and DIXON HT SERIES. Stainless Steel Product. Flat face couplings, with stainless steel (AISI 316) components and seals in Viton. High corrosion resistance. ISO 16028 interchange.

This EH series is interchangeable with the DNP PAO1 SERIES. Steel Product. As the free-flow version of the 75 series, 72 couplings feature an open-passage design with no internal valves, ensuring higher flow efficiency and reduced pressure loss.
