EH 68 Series - NS Agricultural ISO 5675 Quick Couplings, with Ball Valve (Steel)

Share
Categories	Agricultural ISO 5675 Quick Couplers
Trademark/Brand	EH
Interchange	PARKER 4000 SERIES
Interchange	EATON AEROQUIP FD42 SERIES
Interchange	SAFEWAY S20 SERIES
Interchange	STUCCHI IR SERIES
Interchange	DIXON AG SERIES
Interchange	FASTER NS SERIES
Interchange	SNAP-TITE 60 SERIES
Interchange	DNP PDS1 SERIES
Update Time	Dec 16,2025

Detail Information

68 Series

Hydraulic Quick Coupling (Steel)

Ball Valve, ISO-5675

This EH series is interchangeable with PARKER 4000 SERIES, DIXON AG SERIES, EATON AEROQUIP FD42 SERIES, FASTER NS SERIES, DNP PDS1 SERIES, STUCCHI IR SERIES, SAFEWAY S20 SERIES, and SNAP-TITE 60 SERIES. Steel Product. ISO-5675 compliant. General-purpose ball valve couplings with quick-disconnect functionality. ISO-7241-A compliant (1/2'' Body Size Only). The rest body sizes are interchangeable with the PARKER 4000 series and Faster NS series. Note that the FASTER NS SERIES 3/4'' size is different from the PARKER 4000 Series 3/4'' size.

Female

Other Threads/Fitting Ends Are Available Upon Request
Art. No.	Body Size (inch)	Ls(mm)	D(mm)	Hs(mm)	T
HFSFC6814-1/4"	1/4''	52.5	28	S19	1/4"BSPP(NPT)
HFSFC6838-3/8"	3/8''	59.5	35	S22	3/8"BSPP(NPT)
HFSFC6812-1/2"	1/2''	66	38	S27	1/2"BSPP(NPT)
HFSFC6812-3/4"UNF	1/2''	66	38	S27	3/4"-16UNF
HFSFC6834-3/4"	3/4''	80	48	S33	3/4"BSPP(NPT)
HFSFC6810-1"	1''	88.5	52.5	S39	1"BSPP(NPT)

Male

Other Threads/Fitting Ends Are Available Upon Request
Art. No.	Body Size (inch)	Lp(mm)	Hp(mm)	T
HFSFP6814-1/4"	1/4''	35	S19	1/4"BSPP(NPT)
HFSFP6838-3/8"	3/8''	40.5	S24	3/8"BSPP(NPT)
HFSFP6812-1/2"	1/2''	46	S27	1/2"BSPP(NPT)
HFSFP6812-3/4"UNF	1/2''	46	S27	3/4"-16UNF
HFSFP6834-3/4"	3/4''	56.5	S35	3/4"BSPP(NPT)
HFSFP6810-1"	1''	67	S41	1"BSPP(NPT)

Accessories

Color Can Be Customized

Dash Size	ISO Size	Art. No. Dust Plug for Coupler	Art. No. Dust Cap for Plug	Material
04	6.3	ISO-5675-1/4-P-P	ISO-5675-1/4-C-P	PVC
06	10	ISO-5675-3/8-P-P	ISO-5675-3/8-C-P	PVC
08	12.5	ISO-5675-1/2-P-P	ISO-5675-1/2-C-P	PVC
12	20	ISO-5675-3/4-P-P	ISO-5675-3/4-C-P	PVC
16	25	ISO-5675-1-P-P	ISO-5675-1-C-P	PVC

Technical Specifications

Dash Size	Body Size (Inch)	Max. Work PressureMale (bar)	Max. Work PressureFemale (bar)	Max. Work PressureCoupled (bar)	Min. Burst Pressure Male (bar)	Min. Burst Pressure Female (bar)	Min. Burst Pressure Coupled (bar)	Spillage (ml)
04	1/4''	207	207	207	828	828	828	0.7
06	3/8''	207	207	207	828	828	828	1
08	1/2''	207	207	207	828	828	828	1.5
12	3/4''	170	170	170	680	680	680	7
16	1''	150	150	150	600	600	600	11

Material:	Steel
Seals:	NBR, Seals can be customized to meet your special work condition/media
Working Temperatures:	-25 °C to 125 °C, Customizable
Surface Treatment:	MATE 500 (CRIII)
Specifications:	Series Interchange:	PARKER 4000 SERIES, EATON AEROQUIP FD42 SERIES, FASTER NS SERIES, DNP PDS1 SERIES, STUCCHI IR SERIES, SAFEWAY S20 SERIES, VOSWINKEL ID SERIES, DIXON AG SERIES, SNAP-TITE 60 SERIES
	Valve Type:	Ball
	Connection:	Sleeve Retraction
	Disconnection:	Sleeve Retraction
	Connection Under Pressure:	Not Allowed
