EH 105/106 Series - SNAP-TITE H, IH Interchange Quick Coupling Free Flow Available (Steel)

EH 105/106 Series - SNAP-TITE H, IH Interchange Quick Coupling Free Flow Available (Steel)
EH 105/106 Series - SNAP-TITE H, IH Interchange Quick Coupling Free Flow Available (Steel)EH 105/106 Series - SNAP-TITE H, IH Interchange Quick Coupling Free Flow Available (Steel)EH 105/106 Series - SNAP-TITE H, IH Interchange Quick Coupling Free Flow Available (Steel)EH 105/106 Series - SNAP-TITE H, IH Interchange Quick Coupling Free Flow Available (Steel)
Share
CategoriesPoppet (Interchange) Quick Couplers
Trademark/BrandEH
InterchangePARKER H SERIES
InterchangePARKER IH SERIES
InterchangeSNAP-TITE H SERIES
InterchangeSNAP-TITE IH SERIES
InterchangeDIXON V SERIES
InterchangeFASTER TNV SERIES
InterchangeFASTER TNL SERIES
InterchangeDNP PNV1 SERIES
InterchangeDNP PNO1 SERIES
InterchangeSTUCCHI SH SERIES
Update TimeDec 16,2025
Contact Now
Detail Information
Items
Specs
Applications

105 Series / 106 Series

High Pressure Coupling (Steel)

Poppet Valve / Unvalved

This EH series is interchangeable with PARKER H SERIES, PARKER IH SERIES, SNAP-TITE H SERIES, SNAP-TITE IH SERIES, DIXON V SERIES, FASTER TNV SERIES, FASTER TNL SERIES, DNP PNV1 SERIES, DNP PNO1 SERIES and STUCCHI SH SERIES. 105 series couplings are commonly used in US market as an alternative to standard series. Their valves have been designed to help flow and to allow connection with 106 parts (free flow) same series. Carbon Steel.

Female


High Pressure Coupling (Steel) Poppet Valve / Unvalved
105 Series, Other Threads/Fitting Ends Are Available Upon Request
Art. No.
Body Size (inch)
Ls(mm)
D(mm)
Hs(mm)
L(mm)
T
HFSFC10514-1/4"
1/4''
50
24
S22
84
1/4" NPT
HFSFC10538-3/8"
3/8''
57
27
S24
95
3/8 "NPT
HFSFC10512-1/2"
1/2''
65
34
S30
110
1/2" NPT
HFSFC10534-3/4"
3/4''
64
42
S36
106
3/4" NPT
HFSFC10510-1"
1''
71
51
S46
116
1" NPT
HFSFC105114
-1-1/4"
1-1/4''
97
56
S50
164
1-1/4" NPT
HFSFC105112
-1-1/2"
1-1/2''
91
70
S65
148
1-1/2 " NPT
HFSFC10520-2"
2''
102
90
S89
166
2" NPT
106 Series (Unvalved), Other Threads/Fitting Ends Are Available Upon Request
Art. No.
Body Size (inch)
Ls(mm)
D(mm)
Hs(mm)
L(mm)
T
HFSFC10614-1/4"
1/4''
50
24
S22
84
1/4" NPT
HFSFC10638-3/8"
3/8''
57
27
S24
95
3/8 "NPT
HFSFC10612-1/2"
1/2''
65
34
S30
110
1/2" NPT
HFSFC10634-3/4"
3/4''
64
42
S36
106
3/4" NPT
HFSFC10610-1"
1''
71
51
S46
116
1" NPT

Male

High Pressure Coupling (Steel) Poppet Valve / Unvalved
105 Series, Other Threads/Fitting Ends Are Available Upon Request
Art. No.
Body Size (inch)
Lp(mm)
A(mm)
Hp(mm)
L(mm)
T
HFSFP10514-1/4"
1/4''
49
10.8
S22
84
1/4" NPT
HFSFP10538-3/8"
3/8''
57
12.9
S24
95
3/8 "NPT
HFSFP10512-1/2"
1/2''
63
16
S30
110
1/2" NPT
HFSFP10534-3/4"
3/4''
64
23.3
S36
106
3/4" NPT
HFSFP10510-1"
1''
68
29.7
S46
116
1" NPT
HFSFP105114
-1-1/4"
1-1/4''
91
36.1
S50
164
1-1/4" NPT
HFSFP105112
-1-1/2"
1-1/2''
85
43.5
S65
148
1-1/2 " NPT
HFSFP10520-2"
2''
98
56.8
S89
166
2" NPT
106 Series (Unvalved), Other Threads/Fitting Ends Are Available Upon Request
Art. No.
Body Size (inch)
Lp(mm)
A(mm)
Hp(mm)
L(mm)
T
HFSFP10614-1/4"
1/4''
49
10.8
S22
84
1/4" NPT
HFSFP10638-3/8"
3/8''
57
12.9
S24
95
3/8 "NPT
HFSFP10612-1/2"
1/2''
63
16
S30
110
1/2" NPT
HFSFP10634-3/4"
3/4''
64
23.3
S36
106
3/4" NPT
HFSFP10610-1"
1''
68
29.7
S46
116
1" NPT

Accessories


Technical Specifications

105 Series
Dash Size
Body Size (Inch)
Max. Work PressureMale (bar)
Max. Work PressureFemale (bar)
Max. Work PressureCoupled (bar)
Min. Burst
Pressure
Male
(bar)
Min. Burst
Pressure
Female
(bar)
Min. Burst
Pressure
Coupled
(bar)
Spillage
(ml)
04
1/4''
270
270
270
1100
1100
1100
2
06
3/8''
280
280
280
1400
1400
1400
3
08
1/2''
220
220
220
880
880
880
4
12
3/4''
190
190
190
760
760
760
14
16
1''
150
150
150
600
600
600
20
20
1-1/4"
100
100
100
400
400
400
45
24
1-1/2"
100
100
100
400
400
400
80
32
2"
100
100
100
400
400
400
100
106 Series (Unvalved)
Dash Size
Body Size (Inch)
Max. Work PressureMale (bar)
Max. Work PressureFemale (bar)
Max. Work PressureCoupled (bar)
Min. Burst
Pressure
Male
(bar)
Min. Burst
Pressure
Female
(bar)
Min. Burst
Pressure
Coupled
(bar)
Spillage
(ml)
04
1/4''
760
760
760
2000
2000
2000
0
06
3/8''
760
760
760
2000
2000
2000
0
08
1/2''
760
760
760
2000
2000
2000
0
12
3/4''
620
620
620
1300
1300
1300
0
16
1''
400
400
400
1100
1100
1100
0
Material:
Steel
Seals:
NBR, Seals can be customized to meet your special work condition/media
Working Temperatures:
-25 °C to 125 °C, Customizable
Surface Treatment:
MATE 500 (CRIII)
Specifications:
Series Interchange:
PARKER H SERIES, PARKER IH SERIES, SNAP-TITE H SERIES, SNAP-TITE IH SERIES, DIXON V SERIES, FASTER TNV SERIES, FASTER TNL SERIES, DNP PNV1 SERIES, DNP PNO1 SERIES, STUCCHI SH SERIES
Valve Type:
Poppet
Connection:
Sleeve Retraction
Disconnection:
Sleeve Retraction
Connection Under Pressure:
Not Allowed

Pressure Drop
